Grundfos UNILIFT AP12.40.06.1 (Single Phase No Float) – 96001729 Grundfos UNILIFT AP12.40.06.A1 (Single Phase with Float) – 96023929 Grundfos UNILIFT AP12.40.06.3 (Three Phase No Float) – 96001652 Vertical single-stage stainless steel submersible pump with vertical discharge port and integrated submersible available in single phase and three phase totally enclosed motor in insulation class F. The pump is fitted with a suction strainer. The impeller is a SEMI OPEN impeller for groundwater, surface water, rain water and similar. The pump has a double shaft seal and an intermediate oil chamber pre-filled with non-toxic special oil. The pump has a riser pipe, a cooling jacket for continuous cooling of the motor by the pumped liquid and long-life deep-groove greased-for-life ball bearings. The pump is ready for use as it is fitted with carrying handle and is supplied with a 10 m mains cable. The mains cable is of the plug type with glass sealing compound in the socket to prevent penetration of humidity into the stator windings. AP12.40.06.1 | 96001729 AP12.40.06.A1 | 92023929 AP12.40.06.3 | 96001652 Power P2 600W 600W 600W Voltage 240v 240V 3 x 400V Current 4.4A 4.4A 1.6A Flow 300LT/min 300LT/min 300LT/min Head 13m 13m 13m Max Particle 12mm 12mm 12mm Outlet 40mm | 1½” 40mm | 1½” 40mm | 1½” Float No Yes No Dimensions (mm) 321H x 216D 321H x 216D 321H x 216D Weight 12kg 12kg 11kg Power Cable 10m Aus Plug 10m Aus Plug 10m (No Plug) The UNILIFT AP12 is a stainless-steel submersible pump designed for specific water pumping applications. Here are some key features and details about this pump: Material: The pump is made of stainless steel, which is highly resistant to corrosion, making it suitable for various water-related applications. Application: It is designed for pumping non-aggressive water and grey wastewater. This means it’s intended for use with relatively clean water and wastewater that doesn’t contain aggressive chemicals or substances. Particle Size: The pump can handle water and wastewater with particles up to 12 mm in size. This indicates that it can efficiently handle water with small debris or suspended solids without clogging. Versatile: One of the notable features of the UNILIFT AP12 is its versatility. It can be used as a portable unit, meaning it can be easily moved from one location to another, or it can be installed as a stationary unit, where it remains in one place for continuous operation. Submersible: Being a submersible pump means it can be fully immersed in water, which is often the case for applications like drainage or wastewater removal. Usage: Typical applications for pumps like the UNILIFT AP12 include draining flooded areas, emptying tanks or pits, wastewater removal in residential or industrial settings, and similar tasks where water needs to be moved from one location to another. Size and Capacity: Specifics regarding the pump’s size, capacity, and power requirements would depend on the model and specifications of the UNILIFT AP12, which may vary. It’s important to note that when using a submersible pump, proper installation and maintenance are crucial to ensure its longevity and efficient operation. Additionally, it’s essential to follow the manufacturer’s guidelines and recommendations for the specific model you are using.
